Bomford Flailbot Original
Part #: BF-Flailbot
Covering challenging, steeply inclined terrain with a traditional man-on-board power mower puts a driver at risk. Remotely controlled wirelessly, Flailbot provides ultimate mowing capability whilst keeping the operator at a safe distance.
Details
Flailbot Original
The original Flailbot, designed for challenging terrains with the powerful industrial Perkins Diesel engine fitted as standard, providing the ultimate in power to weight performance in the remote controlled track bank mower market.
Covering challenging, steeply inclined terrain with a traditional man-on-board power mower puts a driver at risk. Remotely controlled wirelessly, Flailbot provides ultimate mowing capability whilst keeping the operator at a safe distance.
Key Features
- Working with oil pressure ranges of 180 to 200 BAR
- Working with oil flows between 45 to 110 L/min
- Weight options from 310kg (683lbs) up to 640kg (1,411lbs)
- Skids to protect head
- Adjustable working height
Product Specifications
Standard = Standard Optional = Optional Not Available = Not Available / Not Applicable
| Model | Original (40hp) | ||
|---|---|---|---|
Operation |
|||
| Max Slope | 55° | ||
| Transmission | Hydrostatic | ||
| Speed | 0-7 km/h | ||
| Weight - Fixed Profile | 1200kg / 2,646 lbs | ||
| Weight - Extendable Profile | 1280kg / 2,822 lbs | ||
Engine |
|||
| Brand / Make | Perkins | ||
| Model | 3 Cyclinders, Diesel | ||
| Engine Size | 1,496 Litres / 91,292 in3 | ||
| Power | 30 kW / 40.8 Cv | ||
| Max Torque | 112 Nm / 83 ft-lb@ 1800 rpm | ||
| Intake | Turbocharged | ||
| Cooling | Liquid | ||
| Air Filter | Dry | ||
| Diesel Tank Capacity | 22 Litres / 6 USG | ||
| Engine Oil Capacity | 7 Litres / 2 USG | ||
Electrical Circuit |
|||
| Operating Voltage | 12 Vcc | ||
| Alternator | 65 Amp | ||
| Battery | 60 Ah | ||
Hydraulic System |
|||
| Displacement | Tandem piston pump with variable engine size and closed circuit | ||
| Displacement Capacity | 65 Litres / 17 USG max @ 2750 rpm | ||
| Displacement Pressure | 280 Bar max | ||
| Services | Gear Pump | ||
| Services Capacity | 13 Litres / 3 USG max @ 2750 rpm | ||
| Services Pressure | 200 Bar max | ||
| Tool | Closed Circuit Piston Pump | ||
| Tool Capacity | 58 Litres / 15 USG max @ 2750 rpm | ||
| Tool Pressure | 280 Bar max | ||
| Oil Tank Capacity | 50 Litres / 13 USG | ||
| Operating Oil Quantity | 60 Litres / 16 USG | ||
Controls |
|||
| Brand | Scanreco | ||
| Frequency | 434 Mhz | ||
| Range Signal | 150m / 492' | ||
| Battery | Rechargeable | ||
