DuraDisc HD Disc Mowers

Part #: NH-DuraDisc
Maximize the return of your hay field with improved forage quality and tonnage by choosing the clean, uniform cut that begins at the MowMax cutterbar of New Holland DuraDisc heavy-duty disc mowers.
Details

New Holland Disc Mowers - DuraDisc Series

DEPENDABLE, CLEAN CUTTING WITH TIME-SAVING CONVENIENCE

Forage quality directly influences livestock weight gain and milk production. Maximize the return of your hay field with improved forage quality and tonnage by choosing the clean, uniform cut that begins at the MowMax™ cutterbar of New Holland DuraDisc™ heavy-duty disc mowers. By cutting closely and cleanly, DuraDisc mowers leave less crop behind to increase tonnage with every cutting to boost weight gain, milk production, and ultimately the profitability and success of your operation.

DEPENDABILITY AND CONFIDENCE – MOWMAX™ CUTTERBAR ADVANTAGES

Disc mowers are the first machines to hit the hay fields. Dependable and confident operation comes standard on DuraDisc™ mowers. The MowMax™ cutterbar is backed by the 3-year factory MowMax™ cutterbar warranty for your peace of mind. Each MowMax disc module is an individually sealed gear case with a dedicated oil reservoir so gears always stay lubricated, even when working on hillsides. Each module features a ShockPRO™ hub that absorbs harmful impacts and protects the cutterbar drive if the mower hits an obstruction.

ADAPTS TO ROUGH FIELD CONDITIONS

A large-diameter flotation spring on DuraDisc Series mounted mowers allows the cutterbar to ride smoothly across the field. In addition, a spring-loaded breakaway latch allows the cutterbar to swing back if it hits an immovable object in the field.

DURABILITY, CLEAN CUTTING, LESS DOWNTIME.

You can depend on rugged DuraDisc™ disc mowers to slice through tough conditions, mow smoothly and quickly, and give you the peace of mind you only get with the MowMax™ cutterbar.



Model 107M 108M 109M 210M
 Type Mounted Mounted Mounted Trailed
 Cutter Bar
 Cutting Width 6' 8" 7' 10" 9' 2" 10' 4"
 Cutting Height 1.25" to 3.5" 1.25" to 3.5" 1.25" to 3.5" 0.95" to 3.2"
 Tilt Angle 0° to -10° 0° to -10° 0° to -10° -2° to -10°
 Operating Range +18° to -32° +18° to -30° +18° to -28° +18° to -28°
 Number of Discs 5 6 7 8
 Knives per Disc 2 2 2 2
 Tractor Requirement
 Min PTO Horsepower 45 hp 55 hp 60 hp 60 hp
 Min Relief Pressure 1500 psi 1500 psi 1500 psi 1500 psi
 Hitch Cat. I/II Cat. II quick hitch Drawbar
