W.R. Long Front Blades
W.R. Long Front Blades for Compact Tractors
Front Blade for Sub Compact Tractors (up to 50 hp)
The Front Blade is for Subcompact and Compact Tractors up to 50 hp and is used for pushing snow, sand, dirt, manure, gravel, etc. We can build your front blade with most any type quick attach or pin on connection for no additional charge. The Front Blade comes in 60", 72", 84", and 96" widths and angles up to 30 degrees to the right or left. A manual front blade is available with 5 positions; straight, 15 degrees left or right and 30 degrees left or right.
Front Blade X for Compact Tractors (50 to 90 hp)
The Front Blade X is for 50 to 90 Horsepower tractors and is used for pushing snow, sand, dirt, manure, gravel, etc. We can build your front blade X with most any type quick attach or pin on connection for no additional charge. The Front Blade X comes in 84" and 96" widths and angles up to 30 degrees to the right or left. A manual front blade X is available with 5 positions; straight, 15 degrees left or right and 30 degrees left or right.
Key Benefits
- Replaceable Cutting Edge 1/2" thick by 6" wide and reversible.
- Skid shoes prevent gouging by maintaining the blade at a preset height.
- Spring Trip Blade design so that blade pivots when it hits an obstruction.
- Radius dozer cutting edge available.
- Polyurethane cutting edge available for snow removal.
- Hydraulic blade uses two double acting welded construction cylinders.
- Easily add cylinders and hoses to Manual blade to convert to Hydraulic blade
| FBM | FBH | FBXM | FBXH | |
| Available Widths | 60", 72", 84, 96" | 84", 96", 108" | ||
| Blade Height | 22" | 22" | 30" | 30" |
| Angling | Manual | Hydraulic | Manual | Hydraulic |
| Maximum Angle (L or R) | 30° | 30° | 30° | 30° |
| Horsepower Rating | up to 50 hp | 50 to 90 hp | ||
 |
|
