New Holland Pro-Belt Round Balers
 |
 |
BALERS BUILT FOR BUSINESS
New Holland Pro-Belt™ Series round balers deliver maximum dependability and performance to enhance the productivity of professional haymakers and contractors. Regardless of crop, the Pro-Belt 450 and 460 build high-density, square-shouldered bales time and time again. Build your business by making top-quality bales with a round baler that’s built for business.
COMMERCIAL-GRADE CONSTRUCTION
Professional-grade performance starts with the strong TwinDrive™ gearbox, which evenly distributes PTO power to both sides of the baler for smooth operation and ultimate reliability. Along with a premium oil-filled cut-out clutch, heavy-duty drives with high-quality chains, and a thick steel frame, commercial-grade performance comes standard. In fact, Pro-Belt round balers are 20% heavier than their respective Roll-Belt™ counterparts.
FEEDING AND CUTTING EXCELLENCE
For greater capacity, the SuperFeed™ rotary feeding system and CropCutter® rotary feeding and cutting system both feature a large, 20.5-inch diameter feeder that’s both 14% larger and double the weight of equivalent Roll-Belt models. These rotors offer smooth, “V”-shaped feeding to ensure that crop is directly power-fed across the full width of the chamber to provide excellent feeding and cutting for a baler with a big appetite.
PERFORMANCE TO THE CORE
The Pro-Belt bale chamber is a simple design with few moving parts, which means maximum durability, less maintenance, and greater productivity. Only two fixed bale formation rollers are required to provide aggressive rolling action inside the chamber. When combined with the four, 11-inch-wide, steeply angled premium endless belts, tight cores are quickly and easily formed, leading to dense bales time and time again.
PRECISION TOOLS THAT IMPROVE YOUR PERFORMANCE
A host of precision tools are available to improve your baling experience. If you run the latest high-tech tractors, uncluttering the cab and facilitating ease of use are made possible with premium electronics that work with your tractor’s virtual terminal display and ISOBUS connection. For classic iron, the optional 10.4-inch IntelliView™ IV color touchscreen display and harness offer the same updated interface and controls. To further enhance your productivity, look to New Holland precision solutions like IntelliBale™ and the factory-equipped moisture sensor to work smarter than ever before.
STYLE MEETS FUNCTION
As a nod to our round baler heritage and a bold look to the future, Pro-Belt Series balers sport Natural Flow styling that was first introduced on BigBaler 340 High Density Series large square balers. However, this isn’t a case of style over function – the front and sculpted side shields open wide for easy access during servicing, while yellow paint on the frame enhances visibility from an operational, service, and safety perspective.
| SuperFeed™ | CropCutter® | |||
| Roll-Belt 450 | Roll-Belt 460 | Roll-Belt 450 | Roll-Belt 460 | |
| Bale Size | ||||
| Diameter | 35.5-65" | 35.5-75" | 35.5-65" | 35.5-75" |
| Width | 47.5" | 47.5" | 47.5" | 47.5" |
| Max. Weight | 2879 lbs | 2879 lbs | 2879 lbs | 2879 lbs |
| MaxiSweep Pickup | ||||
| Overall Width | 89.6" | 89.6" | 89.6" | 89.6" |
| Width, tine-to-tine | 81.7" | 81.7" | 81.7" | 81.7" |
| Tine Bars | 5 | 5 | 5 | 5 |
| Number of Tines | 160 | 160 | 160 | 160 |
| Tractor Requirements | ||||
| PTO HP, minimum | 100 hp | 105 hp | 110-120 hp | 120-140 hp |
| PTO Speed | 1000 rpm | 1000 rpm | 1000 rpm | 1000 rpm |
| Hydraulic Remotes | 2 double acting | 2 double acting | ||
Click the "Files" tab above to download full specifications
 |
|
