W.R. Long Brush Grapple
Part #: WRLong-BGrapple
The Root Rake Brush Grapple "RBG" is for Farm, Light Industrial, and Skid Loaders with lift capacities from 1,300 up to 4,000 pounds and comes in widths from 60 inches to 78 inches. Ideal for tree service.
Details
W.R. Long Root Rake Brush Grapple
The Root Rake Brush Grapple "RBG" is for Farm, Light Industrial, and Skid Loaders with lift capacities from 1,300 up to 4,000 pounds and comes in widths from 60 inches to 78 inches. Ideal for tree service. The Root Rake Brush Grapple 2 "RBG-2" is for Compact and Sub Compact Tractors and Mini Skid Steers with lift capacities from 450 up to 1,300 pounds. The Root Rake Brush Grapple is now available with dual grapples.
KEY BENEFITS
- Load center is closer to the loader than on other types of grapples
- Heat treated bushings with stress proof pins
- Root Rake tines have high carbon steel face
- Teeth touch when closed
- Optional Flat Face Hydraulic Quick Couplers, Hydraulic Quick Coupler Kit, and bulk head plate
| Model | RBG2 Series | RBG Series | RBGD Series | |||||||||||
| Width | 38" | 48" | 54" | 60" | 60" | 66" | 72" | 78" | 84" | 60" | 66" | 72" | 78" | 84" |
| No. of Tines | 6 | 6 | 6 | 7 | 7 | 7 | 8 | 8 | 9 | 7 | 7 | 8 | 8 | 9 |
| Weight, lbs | 280 | 325 | 339 | 365 | 567 | 630 | 665 | 743 | 765 | 627 | 690 | 725 | 803 | 825 |
| Open Grapple | 48" | 48" | 48" | 48" | 70" | 70" | 70" | 70" | 70" | 70" | 70" | 70" | 70" | 70" |
| SSL Lift Capacity | 450-1300 lbs | 1300-4000 lbs | 1300-4000 lbs | |||||||||||
 |
|
