Bradco Stump Grinders

Part #: Bradco-SG
Designed specifically for skid steers, these units are available in both standard and high-flow applications, with grinding depths up to 13 inches below the surface. Adjustable swing speeds, multiple tooth configurations and numerous wire harness connections make this the perfect attachment for grinding stumps.
Details
Videos

Bradco Stump Grinders

Designed specifically for skid steers, these units are available in both standard and high-flow applications, with grinding depths up to 13" below the surface. Adjustable swing speeds, multiple tooth configurations and numerous wire harness connections make this the perfect attachment for grinding stumps.

  • Standard flow (SG26) and high-flow (SG30) available for skid steers
  • Tooth pattern permits cutting from side-to-side and vertical directions
  • Wheel and tooth options available
  • Heavy-duty gearbox drives with torque arm motor support for longer motor and drive system life
  • Easy access to all drive components allows for quick maintenance
  • Operates with multi-function control inside the loader
  • Excellent operating visibility & exceptional swing arc geometry
  • Adjustable speed control has been designed into the unit to allow the operator to adjust speed of the swing and lift functions to accommodate maximum performance
  • Built-in grouser pads provide exceptional stability during cutting & grip for your uneven ground and hillsides
  • Optional items include square teeth with single lock nut or shark style teeth with universal bolt pattern



 Model Standard Flow High Flow
SG26 SG30
 Overall Width 58" 58"
 Overall Height 37" 37"
 Overall length 73" 73"
 Below Ground Depth 10" 12"
 Swing Arc 60° 60°
 Maximum Lift 25" 25"
 No. of Cutting Teeth 28 28
 Wheel Diameter 26" 30"
 Hydraulic Flow Required 14-28 gpm 29-44 gpm
 Weight 720 lbs 795 lbs
