New Holland T6 Series Tractors

Part #: NH-T6
T6 Series all-purpose, heavy-duty tractors are redesigned, restyled and ready for the next age of farming. New Holland has combined uncompromised power with the most advanced technology.
Details
Files

New Holland Tractors - T6 Series

DESIGNED FOR THE NEXT AGE OF FARMING

T6 Series all-purpose, heavy-duty tractors are redesigned, restyled and ready for the next age of farming. New Holland has combined uncompromised power with the most advanced technology. They give you unmatched comfort, visibility and maneuverability with higher power and performance that you can feel.

INTRODUCING THE 24X24 DYNAMIC COMMAND™ 8-STEP POWERSHIFT

The transmission selection for T6 tractors now includes a 3-range, 8-step, dual clutch, semi-powershift transmission that provides a full 24 gears in forward and reverse with a true powershuttle transmission. In addition to the Dynamic Command transmission, T6 tractors are also available with the Electro Command™ semi-powershift and Auto Command™ continuously variable transmission (CVT).

LONG 104-INCH WHEELBASE FOR SMOOH RIDE, BETTER TRACTION

New Holland extended the T6 wheelbase to a full 104 inches for the standard front wheel drive (FWD) axle, 110 inches with optional SuperSteer™ FWD axle, 106 inches with the optional TerraGlide™ suspended front axle, and 96 inches for the available 2WD front axle. This long wheelbase design feature makes a noticeable difference, delivering better traction and smoothing your ride during field operation and transport.

EASY MANEUVERING WITH 15' 1" TURN RADIUS (14' 1" WITH SUPERSTEER™ FRONT AXLE OR 2WD AXLE)

Tight turning doesn’t usually go with a long wheelbase, but the T6 Series tractors give you both. The added maneuverability makes a difference when working with a loader and when turning at the headland.

A MODEL AND A PACKAGE TO MATCH YOUR OPERATION

T6 models range from 95 to 125 PTO horsepower, with a choice of 2WD and FWD axles, and in packages to suit your needs.
Value. This package is perfect for basic haying needs and chores.
Plus. This configuration offers increased performance and comfort for haying and loader operations, including optional 31-mph (FWD only).
Elite. This package includes high-performance and luxury features, including optional 31-mph (FWD only).
Dynamic Command™. This configuration provides advanced features that boost productivity and comfort.
Auto Command™. This configuration is the ultimate hay and chore tractor with deluxe features and the highest performance, including a faster 31-mph transmission option.



  T6.145 T6.155 T6.160 T6.175 T6.180
 Engine
 Engine Type Turbo Diesel with Electronic Fuel Delivery Control
 Max Boosted Engine Horsepower 145 hp 155 hp 165 hp 175 hp 175 hp
 Rated Engine Horsepower 116 hp 125 hp 135 hp 145 hp 145 hp
 PTO Horsepower 95 hp 105 hp 115 hp 120 hp 125 hp
 Standard Transmission
 Electro Command Models 16x16 Electro Command (1.41-25 mph)
 Dynamic Command Models 23x23 Dynamic Command (1.41-25 mph)
 Auto Command Models Auto Command CVT (0.01-25 mph)

   Click the "Files" tab above to download full specifications
